8601
Braided PVC TubingProduct Specifications
- Phthalate Free crystal clear tubing handles a variety of food, beverage, and other pure product transfer
- Meets USDA, 3A compliance
- NSF-51 in most sizes, always confirm at time of order
TUBE MATERIAL
PVC
COVER MATERIAL
PVC
PRIMARY APPLICATION
Food Transfer
APPROVALS
FDA
TEMPERATURE MIN. (F)
25
TEMPERATURE MAX. (F)
150
Size Range
Export Specifications
| PART # | HOSE I.D. (inches) |
HOSE O.D. (inches) |
Working Pressure (PSI) |
Burst Pressure (PSI) |
WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|
|
8601-0019
|
0.19 | 0.38 | 250 | 750 | 0.04 | Polyester Spirals |
|
8601-0025
|
0.25 | 0.44 | 250 | 750 | 0.06 | Polyester Spirals |
|
8601-0031
|
0.31 | 0.53 | 250 | 750 | 0.08 | Polyester Spirals |
|
8601-0038
|
0.38 | 0.59 | 225 | 675 | 0.09 | Polyester Spirals |
|
8601-0050
|
0.5 | 0.75 | 200 | 600 | 0.13 | Polyester Spirals |
|
8601-0063
|
0.63 | 0.89 | 200 | 600 | 0.18 | Polyester Spirals |
|
8601-0075
|
0.75 | 1.03 | 150 | 450 | 0.22 | Polyester Spirals |
|
8601-0100
|
1 | 1.3 | 125 | 375 | 0.3 | Polyester Spirals |
|
8601-0125
|
1.25 | 1.62 | 100 | 300 | 0.46 | Polyester Spirals |
|
8601-0150
|
1.5 | 1.94 | 100 | 300 | 0.64 | Polyester Spirals |
|
8601-0200
|
2 | 2.49 | 75 | 225 | 0.95 | Polyester Spirals |
