7802
HD PVC Discharge HoseProduct Specifications
- Water discharge service where elevated working pressure or a heavier wall for abrasion resistance is desired
- MSHA rated hose available upon request
- Roll lengths up to 300 ft continuous most sizes
TUBE MATERIAL
PVC
COVER MATERIAL
PVC
PRIMARY APPLICATION
Water Discharge
TEMPERATURE MIN. (F)
-5
TEMPERATURE MAX. (F)
140
Size Range
Export Specifications
| PART # | HOSE I.D. (inches) |
HOSE O.D. (inches) |
Working Pressure (PSI) |
Burst Pressure (PSI) |
WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|
|
7802-0150
|
1.5 | 1.78 | 150 | 450 | 0.23 | 3-Ply Polyester Yarn |
|
7802-0200
|
2 | 2.27 | 150 | 450 | 0.32 | 3-Ply Polyester Yarn |
|
7802-0250
|
2.5 | 2.77 | 150 | 450 | 0.41 | 3-Ply Polyester Yarn |
|
7802-0300
|
3 | 3.29 | 150 | 450 | 0.52 | 3-Ply Polyester Yarn |
|
7802-0400
|
4 | 4.32 | 125 | 375 | 0.76 | 3-Ply Polyester Yarn |
|
7802-0600
|
6 | 6.39 | 115 | 345 | 1.21 | 3-Ply Polyester Yarn |
|
7802-0800
|
8 | 8.39 | 70 | 210 | 1.62 | 3-Ply Polyester Yarn |
|
7802-1000
|
10 | 10.38 | 65 | 195 | 1.95 | 3-Ply Polyester Yarn |
