7801
Product Specifications
- Open-ended low pressure water discharge in agriculture, construction, and general dewatering
- Also see 7802 for red heavier grade
- Roll lengths up to 300 ft continuous
TUBE MATERIAL
PVC
COVER MATERIAL
PVC
PRIMARY APPLICATION
Water Discharge
TEMPERATURE MIN. (F)
-5
TEMPERATURE MAX. (F)
170
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) | HOSE O.D. (inches) | Working Pressure (PSI) | Burst Pressure (PSI) | WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|
|
7801-0075
|
0.75 | 0.88 | 140 | 425 | 0.08 | 3-Ply Polyester Yarn |
|
7801-0100
|
1.00 | 1.14 | 110 | 340 | 0.10 | 3-Ply Polyester Yarn |
|
7801-0125
|
1.25 | 1.41 | 80 | 255 | 0.14 | 3-Ply Polyester Yarn |
|
7801-0150
|
1.50 | 1.73 | 80 | 240 | 0.19 | 3-Ply Polyester Yarn |
|
7801-0200
|
2.00 | 2.21 | 80 | 240 | 0.24 | 3-Ply Polyester Yarn |
|
7801-0250
|
2.50 | 2.68 | 65 | 200 | 0.30 | 3-Ply Polyester Yarn |
|
7801-0300
|
3.00 | 3.20 | 80 | 240 | 0.36 | 3-Ply Polyester Yarn |
|
7801-0400
|
4.00 | 4.27 | 70 | 210 | 0.53 | 3-Ply Polyester Yarn |
|
7801-0500
|
5.00 | 5.21 | 40 | 130 | 0.63 | 3-Ply Polyester Yarn |
|
7801-0600
|
6.00 | 6.31 | 60 | 200 | 0.86 | 3-Ply Polyester Yarn |
|
7801-0800
|
8.00 | 8.32 | 35 | 100 | 1.30 | 3-Ply Polyester Yarn |
|
7801-1000
|
10.00 | 10.42 | 35 | 100 | 1.88 | 3-Ply Polyester Yarn |
|
7801-1200
|
12.00 | 12.36 | 35 | 100 | 2.43 | 3-Ply Polyester Yarn |
|
7801-1400
|
14.00 | 14.38 | 30 | 85 | 2.70 | 3-Ply Polyester Yarn |
|
7801-1600
|
16.00 | 16.38 | 30 | 85 | 3.08 | 3-Ply Polyester Yarn |
