1535
Product Specifications
- Designed for the transfer of propane and butane, and natural gas in open and well ventilated environments
- Not to exceed 1 psiG for natural gas use
- Do not operate over 100 Deg F in gas applications
TUBE MATERIAL
Synthetic Blend
COVER MATERIAL
Synthetic Blend
PRIMARY APPLICATION
LP Gas
APPROVALS
UL21
TEMPERATURE MIN. (F)
-40
TEMPERATURE MAX. (F)
180
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) | HOSE O.D. (inches) | Working Pressure (PSI) | Burst Pressure (PSI) | Min. Bend Radius (Inches) | WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
1535-0025
|
0.25 | 0.59 | 350 | 1750 | 1.5 | 0.12 | Multiple Spirals Textile |
|
1535-0038
|
0.38 | 0.72 | 350 | 1750 | 2.5 | 0.18 | Multiple Spirals Textile |
|
1535-0050
|
0.50 | 0.92 | 350 | 1750 | 3 | 0.25 | Multiple Spirals Textile |
|
1535-0075
|
0.75 | 1.23 | 350 | 1750 | 5 | 0.41 | Multiple Spirals Textile |
|
1535-0100
|
1.00 | 1.50 | 350 | 1750 | 7.5 | 0.52 | Multiple Spirals Textile |
|
1535-0125
|
1.25 | 1.81 | 350 | 1750 | 13 | 0.80 | Multiple Spirals Textile |
|
1535-0150
|
1.50 | 2.05 | 350 | 1750 | 18 | 1.00 | Multiple Spirals Textile |
