1522
General Service - Black 200Product Specifications
- A General purpose air and water hose with excellent outdoor weathering characteristics
- See 1502 series for red cover version
TUBE MATERIAL
EPDM
COVER MATERIAL
EPDM
PRIMARY APPLICATION
Air/Water
TEMPERATURE MIN. (F)
-40
TEMPERATURE MAX. (F)
212
Size Range
Export Specifications
| PART # | HOSE I.D. (inches) |
HOSE O.D. (inches) |
Working Pressure (PSI) |
Burst Pressure (PSI) |
Min. Bend Radius (Inches) |
WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
1522-0025
|
0.25 | 0.5 | 200 | 800 | 2.5 | 0.09 | 2-Ply Textile |
|
1522-0038
|
0.38 | 0.68 | 200 | 800 | 3.5 | 0.15 | 2-Ply Textile |
|
1522-0050
|
0.5 | 0.81 | 200 | 800 | 4.5 | 0.2 | 2-Ply Textile |
|
1522-0063
|
0.63 | 0.97 | 200 | 800 | 5.5 | 0.25 | 2-Ply Textile |
|
1522-0075
|
0.75 | 1.11 | 200 | 800 | 6 | 0.33 | 2-Ply Textile |
|
1522-0100
|
1 | 1.41 | 200 | 800 | 7 | 0.47 | 2-Ply Textile |
|
1522-0125
|
1.25 | 1.73 | 200 | 800 | 8.5 | 0.75 | 2-Ply Textile |
|
1522-0150
|
1.5 | 1.98 | 200 | 800 | 10.5 | 0.86 | 2-Ply Textile |
|
1522-0200
|
2 | 2.55 | 200 | 800 | 14 | 1.08 | 2-Ply Textile |
