3TB0
Product Specifications
- A 100R18 medium pressure hydraulic hose with low-temperature capability for all season environments
- Use in telehandler, utility vehicles, rescue equipment, forklifts, foam and light chemical transfer
- Temperature max capable to 200 deg F in oil based applications
TUBE MATERIAL
PET
COVER MATERIAL
Polyurethane
TEMPERATURE MIN. (F)
-65
TEMPERATURE MAX. (F)
150
INDUSTRY STANDARDS
SAE100R18
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) | HOSE O.D. (inches) | Working Pressure (PSI) | Burst Pressure (PSI) | Min. Bend Radius (Inches) | WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
3TB0-06
|
0.38 | 0.67 | 3920 | 15680 | 2.05 | 0.12 | 2-Textile Braid |
|
3TB0-08
|
0.50 | 0.85 | 3920 | 15680 | 3.5 | 0.17 | 2-Textile Braid |
|
3TB0-10
|
0.63 | 1.06 | 3920 | 15680 | 4 | 0.28 | 2-Textile Braid |
|
3TB0-06-2
|
0.38 | 0.67 | 3920 | 15680 | 2.05 | 0.12 | 2-Textile Braid |
|
3TB0-08-2
|
0.50 | 0.85 | 3920 | 15680 | 3.5 | 0.17 | 2-Textile Braid |
|
3TB0-10-2
|
0.63 | 1.06 | 3920 | 15680 | 4 | 0.28 | 2-Textile Braid |
