1300
Product Specifications
- Alumimum composite lined tubing can be bent on site with minimal install time
- Can be used in-ground without conduit or protective sleeve
- Pneumatic instrumentation and air sampling in wet or moist environments
TUBE MATERIAL
Aluminum Composite
COVER MATERIAL
Polyurethane
TEMPERATURE MIN. (F)
-40
TEMPERATURE MAX. (F)
179
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) | HOSE O.D. (inches) | Working Pressure (PSI) | Burst Pressure (PSI) | Min. Bend Radius (Inches) | WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
1300-044
|
0.17 | 0.25 | 418 | 1668 | 0.75 | 0.016 | None |
|
1300-066
|
0.25 | 0.37 | 418 | 1668 | 1.26 | 0.034 | None |
|
1300-086
|
0.38 | 0.5 | 355 | 1305 | 1.97 | 0.046 | None |
|
1300-M06
|
0.16 | 0.24 | 418 | 1668 | 0.75 | 0.016 | None |
|
1300-M08
|
0.21 | 0.31 | 418 | 1668 | 0.98 | 0.026 | None |
|
1300-M10
|
0.24 | 0.39 | 418 | 1668 | 1.26 | 0.039 | None |
|
1300-M12
|
0.32 | 0.47 | 355 | 1421 | 1.57 | 0.05 | None |
|
1300-M14
|
0.38 | 0.55 | 355 | 1305 | 1.97 | 0.065 | None |
|
1300-M15
|
0.42 | 0.59 | 290 | 943 | 1.97 | 0.069 | None |
