T1809
Convoluted Conductive PTFEProduct Specifications
- Convoluted PTFE with 304 SS braid
- Electrically conductive tube
- See T1794 for non-conductive version
PRIMARY APPLICATION
Food Transfer
TEMPERATURE MIN. (F)
-76
TEMPERATURE MAX. (F)
500
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) |
HOSE O.D. (inches) |
Working Pressure (PSI) |
Burst Pressure (PSI) |
Min. Bend Radius (Inches) |
WEIGHT: LBS / FT |
|---|---|---|---|---|---|---|
|
T1809-04
|
0.25 | 0.49 | 2500 | 7500 | 0.7 | 0.11 |
|
T1809-06
|
0.38 | 0.6 | 2000 | 6000 | 0.8 | 0.18 |
|
T1809-08
|
0.5 | 0.74 | 1500 | 4500 | 1 | 0.24 |
|
T1809-10
|
0.63 | 0.87 | 1200 | 3600 | 2 | 0.33 |
|
T1809-12
|
0.75 | 0.97 | 1000 | 3000 | 2.5 | 0.66 |
|
T1809-16
|
1 | 1.29 | 670 | 2000 | 3.5 | 1.02 |
|
T1809-20
|
1.25 | 1.61 | 500 | 1500 | 5 | 1.68 |
|
T1809-24
|
1.5 | 1.9 | 440 | 1300 | 6 | 2.59 |
|
T1809-32
|
2 | 2.42 | 335 | 1000 | 7.5 |
