H1196
Product Specifications
- A highly versatile hose for water, liquid waste, and agricultural solutions
- Will not collapse under elevated temperatures or bends
- Capable of full vacuum service in all sizes
TUBE MATERIAL
PVC
COVER MATERIAL
PVC
PRIMARY APPLICATION
Water Suction
APPROVALS
MSHA
TEMPERATURE MIN. (F)
-20
TEMPERATURE MAX. (F)
180
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) | HOSE O.D. (inches) | Working Pressure (PSI) | Burst Pressure (PSI) | Min. Bend Radius (Inches) | WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
H1196-24
|
1.50 | 2.00 | 300 | 900 | 6 | 0.81 | Wire Helix & Textile plies |
|
H1196-32
|
2.00 | 2.50 | 300 | 900 | 8 | 1.10 | Wire Helix & Textile plies |
|
H1196-40
|
2.50 | 3.00 | 300 | 900 | 10 | 1.34 | Wire Helix & Textile plies |
|
H1196-48
|
3.00 | 3.50 | 250 | 750 | 12 | 2.00 | Wire Helix & Textile plies |
|
H1196-64
|
4.00 | 4.50 | 200 | 600 | 16 | 2.72 | Wire Helix & Textile plies |
