9904
Product Specifications
- A versatile all-season hose for pump suction, water transfer, and wastewater vacuum trucks
- Also suitable for low pressure discharge service with submersible pumps
TUBE MATERIAL
EPDM
COVER MATERIAL
Polyethylene
PRIMARY APPLICATION
Water Suction
TEMPERATURE MIN. (F)
-30
TEMPERATURE MAX. (F)
140
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) | HOSE O.D. (inches) | Working Pressure (PSI) | Burst Pressure (PSI) | Min. Bend Radius (Inches) | WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
9904GN-0100
|
1.00 | 1.36 | 80 | 240 | 4 | 0.23 | Cover acts as the reinforcement |
|
9904GN-0125
|
1.25 | 1.61 | 70 | 210 | 5 | 0.30 | Cover acts as the reinforcement |
|
9904GN-0150
|
1.50 | 1.96 | 60 | 180 | 6 | 0.49 | Cover acts as the reinforcement |
|
9904GN-0200
|
2.00 | 2.49 | 50 | 150 | 9 | 0.69 | Cover acts as the reinforcement |
|
9904GN-0250
|
2.50 | 3.02 | 45 | 135 | 11 | 0.91 | Cover acts as the reinforcement |
|
9904GN-0300
|
3.00 | 3.60 | 45 | 135 | 12 | 1.21 | Cover acts as the reinforcement |
|
9904GN-0400
|
4.00 | 4.69 | 40 | 120 | 15 | 1.83 | Cover acts as the reinforcement |
|
9904GN-0600
|
6.00 | 6.86 | 30 | 90 | 20 | 3.84 | Cover acts as the reinforcement |
|
9904GY-0100
|
1.00 | 1.36 | 80 | 240 | 4 | 0.23 | Cover acts as the reinforcement |
|
9904GY-0125
|
1.25 | 1.61 | 70 | 210 | 5 | 0.30 | Cover acts as the reinforcement |
|
9904GY-0150
|
1.50 | 1.96 | 60 | 180 | 6 | 0.49 | Cover acts as the reinforcement |
|
9904GY-0200
|
2.00 | 2.49 | 50 | 150 | 9 | 0.69 | Cover acts as the reinforcement |
|
9904GY-0250
|
2.50 | 3.02 | 45 | 135 | 11 | 0.91 | Cover acts as the reinforcement |
|
9904GY-0300
|
3.00 | 3.60 | 45 | 135 | 12 | 1.21 | Cover acts as the reinforcement |
|
9904GY-0400
|
4.00 | 4.69 | 40 | 120 | 15 | 1.83 | Cover acts as the reinforcement |
|
9904GY-0600
|
6.00 | 6.86 | 30 | 90 | 20 | 3.84 | Cover acts as the reinforcement |
