9822
Nitrile Discharge HoseProduct Specifications
- A heavier grade layflat hose with an excellent combination of working pressure, weight, and abrasion resistance
- Approved for pneumatic service at decreased working pressure limits, inquire
- Unique construction resists kinking, twisting, and snaking - long length rolls available
TUBE MATERIAL
PVC/ Nitrile Blend
COVER MATERIAL
PVC/ Nitrile Blend
PRIMARY APPLICATION
Water Discharge
TEMPERATURE MIN. (F)
-22
TEMPERATURE MAX. (F)
176
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) |
HOSE O.D. (inches) |
Burst Pressure (PSI) |
WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|
|
9822BK-0600
|
6 | 6.38 | 725 | 1.68 | Woven Polyester |
|
9822BK-0800
|
8 | 8.39 | 500 | 2.22 | Woven Polyester |
|
9822BK-1000
|
10 | 10.36 | 500 | 2.65 | Woven Polyester |
|
9822BK-1200
|
12 | 12.41 | 375 | 3.43 | Woven Polyester |
|
9822YW-0075
|
0.75 | 1.03 | 1450 | 0.13 | Woven Polyester |
|
9822YW-0100
|
1 | 1.23 | 1660 | 0.17 | Woven Polyester |
|
9822YW-0150
|
1.5 | 1.77 | 910 | 0.3 | Woven Polyester |
|
9822YW-0200
|
2 | 2.35 | 910 | 0.43 | Woven Polyester |
|
9822YW-0250
|
2.5 | 2.83 | 750 | 0.47 | Woven Polyester |
|
9822YW-0300
|
3 | 3.27 | 650 | 0.61 | Woven Polyester |
|
9822YW-0400
|
4 | 4.28 | 750 | 0.84 | Woven Polyester |
|
9822YW-0600
|
6 | 6.38 | 725 | 1.68 | Woven Polyester |
