8605
Product Specifications
- Phthalate Free high purity hose for deionized water and potable water, and other pure fluids service
- Manufactured with NSF-51/NSF-61 certified compounds, RoHS compliant.
- Non-conductive and non-marking
TUBE MATERIAL
PVC
COVER MATERIAL
PVC
PRIMARY APPLICATION
Food Transfer
APPROVALS
FDA
TEMPERATURE MIN. (F)
25
TEMPERATURE MAX. (F)
150
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) | HOSE O.D. (inches) | Working Pressure (PSI) | Burst Pressure (PSI) | WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|
|
8605-0038
|
0.38 | 0.60 | 225 | 675 | 0.09 | Multiple Textile Plies |
|
8605-0050
|
0.50 | 0.75 | 200 | 600 | 0.14 | Multiple Textile Plies |
|
8605-0075
|
0.75 | 1.03 | 150 | 450 | 0.22 | Multiple Textile Plies |
|
8605-0100
|
1.00 | 1.30 | 125 | 375 | 0.30 | Multiple Textile Plies |
