7904
Product Specifications
- For food, beverage, and other pure liquid suction and transfer
- Available with a copper ground wire most sizes, see 7904W
- Additional sizes, including metric, available by special order
TUBE MATERIAL
PVC
COVER MATERIAL
Corrugated PVC Helix
PRIMARY APPLICATION
Food Transfer
APPROVALS
FDA
TEMPERATURE MIN. (F)
-4
TEMPERATURE MAX. (F)
150
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) | HOSE O.D. (inches) | Working Pressure (PSI) | Burst Pressure (PSI) | Min. Bend Radius (Inches) | WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
7904-0100
|
1.00 | 1.30 | 55 | 165 | 2 | 0.21 | Cover acts as the reinforcement |
|
7904-0125
|
1.25 | 1.60 | 50 | 150 | 3 | 0.28 | Cover acts as the reinforcement |
|
7904-0150
|
1.50 | 1.92 | 50 | 150 | 4 | 0.35 | Cover acts as the reinforcement |
|
7904-0200
|
2.00 | 2.40 | 40 | 120 | 4 | 0.56 | Cover acts as the reinforcement |
|
7904-0225
|
2.25 | 2.74 | 40 | 120 | 5 | 0.65 | Cover acts as the reinforcement |
|
7904-0250
|
2.50 | 3.00 | 40 | 120 | 6 | 0.77 | Cover acts as the reinforcement |
|
7904-0300
|
3.00 | 3.64 | 40 | 120 | 7 | 1.10 | Cover acts as the reinforcement |
|
7904-0400
|
4.00 | 4.72 | 35 | 105 | 10 | 1.80 | Cover acts as the reinforcement |
