5901
Product Specifications
- For wet and dry abrasive transfer where a black tube is acceptable
- See 5903 for white FDA rated tube version
- 3/16 thick gum tube standard most sizes, thicker linings and other lining materials available
TUBE MATERIAL
Black Natural Rubber blend
COVER MATERIAL
Natural Rubber / SBR blend
PRIMARY APPLICATION
Material Handling
TEMPERATURE MIN. (F)
-22
TEMPERATURE MAX. (F)
176
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) | HOSE O.D. (inches) | Working Pressure (PSI) | Burst Pressure (PSI) | Min. Bend Radius (Inches) | WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
5901-0200
|
2.00 | 2.56 | 150 | 600 | 8 | 0.97 | Multiple textile plies & wire helix |
|
5901-0250
|
2.50 | 2.80 | 125 | 500 | 9 | 2.26 | Multiple textile plies & wire helix |
|
5901-0300
|
3.00 | 3.54 | 150 | 600 | 12 | 1.59 | Multiple textile plies & wire helix |
|
5901-0400
|
4.00 | 4.57 | 150 | 600 | 14 | 2.20 | Multiple textile plies & wire helix |
|
5901-0500
|
5.00 | 5.63 | 75 | 300 | 24 | 3.25 | Multiple textile plies & wire helix |
|
5901-0600
|
6.00 | 6.61 | 75 | 300 | 28 | 4.05 | Multiple textile plies & wire helix |
|
5901-0800
|
8.00 | 8.70 | 75 | 300 | 36 | 6.15 | Multiple textile plies & wire helix |
|
5901-1000
|
10.00 | 11.16 | 50 | 200 | 22 | 13.90 | Multiple textile plies & wire helix |
|
5901-1200
|
12.00 | 13.24 | 50 | 200 | 28 | 17.62 | Multiple textile plies & wire helix |
