5705
Product Specifications
- A premium hose designed for long service life for in-plant and steam cleaning applications -Unique barber pole cover design
- Factory approved crimp coupling program ensures a leak-free assembly design
- Rated to 450 deg F superheated steam - intemittent service only
TUBE MATERIAL
Chlorobutyl
COVER MATERIAL
EPDM
PRIMARY APPLICATION
Steam
TEMPERATURE MIN. (F)
-40
TEMPERATURE MAX. (F)
407
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) | HOSE O.D. (inches) | Working Pressure (PSI) | Burst Pressure (PSI) | Min. Bend Radius (Inches) | WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
5705-0050
|
0.50 | 1.08 | 250 | 2500 | 7 | 0.54 | 2-wire braid |
|
5705-0075
|
0.75 | 1.32 | 250 | 2500 | 9.5 | 0.69 | 2-wire braid |
|
5705-0100
|
1.00 | 1.59 | 250 | 2500 | 12 | 0.90 | 2-wire braid |
