4503
Product Specifications
- For plant and food processing facility washdown service in oily environments
- Highly abrasion resistant cover
TUBE MATERIAL
Nitrile
COVER MATERIAL
Carboxylated Nitrile Blend
PRIMARY APPLICATION
Plant Washdown
TEMPERATURE MIN. (F)
-20
TEMPERATURE MAX. (F)
210
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) | HOSE O.D. (inches) | Working Pressure (PSI) | Burst Pressure (PSI) | WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|
|
4503BL-0050
|
0.50 | 0.90 | 300 | 1200 | 0.45 | Multiple Spirals Textile |
|
4503BL-0063
|
0.63 | 1.06 | 300 | 1200 | 0.62 | Multiple Spirals Textile |
|
4503BL-0075
|
0.75 | 1.19 | 300 | 1200 | 0.65 | Multiple Spirals Textile |
|
4503BL-0100
|
1.00 | 1.50 | 300 | 1200 | 0.95 | Multiple Spirals Textile |
|
4503YW-0050
|
0.50 | 0.90 | 300 | 1200 | 0.43 | Multiple Spirals Textile |
|
4503YW-0075
|
0.75 | 1.19 | 300 | 1200 | 0.61 | Multiple Spirals Textile |
|
4503YW-0100
|
1.00 | 1.50 | 300 | 1200 | 0.89 | Multiple Spirals Textile |
