3200
Double Jacket MillProduct Specifications
- An all-season layflat hose for dewatering & hydrant water supply on jobsites
- Double jacket adds protection in abrasive and abusive environments
- Not for fire protection service
TUBE MATERIAL
NR/SBR Blend
COVER MATERIAL
Polyester weave
PRIMARY APPLICATION
Water Discharge
TEMPERATURE MIN. (F)
-20
TEMPERATURE MAX. (F)
158
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) |
HOSE O.D. (inches) |
Burst Pressure (PSI) |
WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|
|
3200-0100
|
1 | 1.13 | 300 | 0.17 | Cover acts as the reinforcement |
|
3200-0150
|
1.5 | 1.68 | 300 | 0.2 | Cover acts as the reinforcement |
|
3200-0200
|
2 | 2.19 | 300 | 0.27 | Cover acts as the reinforcement |
|
3200-0250
|
2.5 | 2.65 | 300 | 0.37 | Cover acts as the reinforcement |
|
3200-0300
|
3 | 3.19 | 300 | 0.43 | Cover acts as the reinforcement |
|
3200-0400
|
4 | 4.81 | 300 | 0.62 | Cover acts as the reinforcement |
|
3200-0600
|
6 | 6.25 | 230 | 1.1 | Cover acts as the reinforcement |
|
3220-0150
|
1.5 | 1.8 | 500 | 0.29 | Cover acts as the reinforcement |
|
3220-0200
|
2 | 2.12 | 500 | 0.4 | Cover acts as the reinforcement |
|
3220-0250
|
2.5 | 2.77 | 500 | 0.5 | Cover acts as the reinforcement |
|
3220-0300
|
3 | 3.32 | 500 | 0.63 | Cover acts as the reinforcement |
|
3220-0400
|
4 | 4.93 | 500 | 0.76 | Cover acts as the reinforcement |
