2902
Product Specifications
- Handles 98% of chemical and acid solutions (verify before using)
- Corrugated cover for high flexibilty
- Max temp rating is for intermittent service only
TUBE MATERIAL
UHMW Polyethylene
COVER MATERIAL
EPDM
PRIMARY APPLICATION
Chemical
TEMPERATURE MIN. (F)
-40
TEMPERATURE MAX. (F)
194
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) | HOSE O.D. (inches) | Working Pressure (PSI) | Burst Pressure (PSI) | Min. Bend Radius (Inches) | WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
2902BU-0075
|
0.75 | 1.14 | 200 | 600 | 6 | 0.38 | Textile plies and wire helix |
|
2902BU-0100
|
1.00 | 1.44 | 200 | 800 | 2.5 | 0.57 | Textile plies and dual wire helix |
|
2902BU-0125
|
1.25 | 1.71 | 200 | 800 | 3 | 0.62 | Textile plies and dual wire helix |
|
2902BU-0150
|
1.50 | 1.96 | 200 | 800 | 3 | 0.82 | Textile plies and dual wire helix |
|
2902BU-0200
|
2.00 | 2.49 | 200 | 800 | 4 | 1.11 | Textile plies and dual wire helix |
|
2902BU-0250
|
2.50 | 2.99 | 200 | 800 | 5 | 1.40 | Textile plies and dual wire helix |
|
2902BU-0300
|
3.00 | 3.55 | 200 | 800 | 6 | 1.77 | Textile plies and dual wire helix |
|
2902BU-0400
|
4.00 | 4.56 | 200 | 800 | 8 | 2.74 | Textile plies and dual wire helix |
|
2902BU-0600
|
6.00 | 6.83 | 200 | 800 | 20 | 5.50 | Textile plies and dual wire helix |
|
2902GN-0100
|
1.00 | 1.44 | 200 | 800 | 2.5 | 0.57 | Textile plies and dual wire helix |
|
2902GN-0150
|
1.50 | 1.96 | 200 | 800 | 3 | 0.82 | Textile plies and dual wire helix |
|
2902GN-0200
|
2.00 | 2.49 | 200 | 800 | 4 | 1.11 | Textile plies and dual wire helix |
|
2902GN-0250
|
2.50 | 2.99 | 200 | 800 | 5 | 1.40 | Textile plies and dual wire helix |
|
2902GN-0300
|
3.00 | 3.55 | 200 | 800 | 6 | 1.77 | Textile plies and dual wire helix |
|
2902GN-0400
|
4.00 | 4.56 | 200 | 800 | 8 | 2.74 | Textile plies and dual wire helix |
|
2902GN-0600
|
6.00 | 6.83 | 200 | 800 | 20 | 5.50 | Textile plies and dual wire helix |
|
2902PR-0100
|
1.00 | 1.52 | 300 | 1200 | 3 | 0.55 | Textile plies and dual wire helix |
|
2902PR-0150
|
1.50 | 2.13 | 300 | 1200 | 4 | 0.89 | Textile plies and dual wire helix |
|
2902PR-0200
|
2.00 | 2.63 | 300 | 1200 | 5 | 1.16 | Textile plies and dual wire helix |
|
2902PR-0300
|
3.00 | 3.63 | 250 | 1000 | 6.5 | 1.68 | Textile plies and dual wire helix |
|
2902PR-0400
|
4.00 | 4.67 | 175 | 700 | 9.5 | 2.26 | Textile plies and dual wire helix |
