1509
Product Specifications
- Compatible with fuel, lubricating oils, air and water
- Pairs with push-lock hose couplings to eliminate the need for a hose clamp
- RMA Class A oil resistant tube
TUBE MATERIAL
Nitrile
COVER MATERIAL
Synthetic Blend
PRIMARY APPLICATION
Air/Water
TEMPERATURE MIN. (F)
-40
TEMPERATURE MAX. (F)
212
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) | HOSE O.D. (inches) | Working Pressure (PSI) | Burst Pressure (PSI) | Min. Bend Radius (Inches) | WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
1509BK-0025
|
0.25 | 0.50 | 300 | 1200 | 3 | 0.09 | 1 Fiber Braid |
|
1509BK-0038
|
0.38 | 0.67 | 300 | 1200 | 3 | 0.13 | 1 Fiber Braid |
|
1509BK-0050
|
0.50 | 0.77 | 300 | 1200 | 5 | 0.15 | 1 Fiber Braid |
|
1509BK-0063
|
0.63 | 0.93 | 300 | 1200 | 6 | 0.23 | 1 Fiber Braid |
|
1509BK-0075
|
0.75 | 1.04 | 300 | 1200 | 6 | 0.26 | 1 Fiber Braid |
|
1509BK-0100
|
1.00 | 1.38 | 200 | 800 | 10 | 0.38 | 1 Fiber Braid |
|
1509BU-0025
|
0.25 | 0.50 | 300 | 1200 | 3 | 0.09 | 1 Fiber Braid |
|
1509BU-0038
|
0.38 | 0.67 | 300 | 1200 | 3 | 0.13 | 1 Fiber Braid |
|
1509BU-0050
|
0.50 | 0.77 | 300 | 1200 | 5 | 0.15 | 1 Fiber Braid |
|
1509BU-0063
|
0.63 | 0.93 | 300 | 1200 | 6 | 0.23 | 1 Fiber Braid |
|
1509BU-0075
|
0.75 | 1.04 | 300 | 1200 | 6 | 0.26 | 1 Fiber Braid |
|
1509BU-0100
|
1.00 | 1.38 | 200 | 800 | 10 | 0.38 | 1 Fiber Braid |
|
1509GN-0025
|
0.25 | 0.50 | 300 | 1200 | 3 | 0.09 | 1 Fiber Braid |
|
1509GN-0038
|
0.38 | 0.67 | 300 | 1200 | 3 | 0.13 | 1 Fiber Braid |
|
1509GN-0050
|
0.50 | 0.77 | 300 | 1200 | 5 | 0.15 | 1 Fiber Braid |
|
1509GN-0063
|
0.63 | 0.93 | 300 | 1200 | 6 | 0.23 | 1 Fiber Braid |
|
1509GN-0075
|
0.75 | 1.04 | 300 | 1200 | 6 | 0.26 | 1 Fiber Braid |
|
1509GY-0025
|
0.25 | 0.50 | 300 | 1200 | 3 | 0.09 | 1 Fiber Braid |
|
1509GY-0038
|
0.38 | 0.67 | 300 | 1200 | 3 | 0.13 | 1 Fiber Braid |
|
1509GY-0050
|
0.50 | 0.77 | 300 | 1200 | 5 | 0.15 | 1 Fiber Braid |
|
1509GY-0063
|
0.63 | 0.93 | 300 | 1200 | 6 | 0.23 | 1 Fiber Braid |
|
1509GY-0075
|
0.75 | 1.04 | 300 | 1200 | 6 | 0.26 | 1 Fiber Braid |
|
1509RD-0025
|
0.25 | 0.50 | 300 | 1200 | 3 | 0.09 | 1 Fiber Braid |
|
1509RD-0038
|
0.38 | 0.67 | 300 | 1200 | 3 | 0.13 | 1 Fiber Braid |
|
1509RD-0050
|
0.50 | 0.77 | 300 | 1200 | 5 | 0.15 | 1 Fiber Braid |
|
1509RD-0063
|
0.63 | 0.93 | 300 | 1200 | 6 | 0.23 | 1 Fiber Braid |
|
1509RD-0075
|
0.75 | 1.04 | 300 | 1200 | 6 | 0.26 | 1 Fiber Braid |
|
1509YW-0025
|
0.25 | 0.50 | 300 | 1200 | 3 | 0.09 | 1 Fiber Braid |
|
1509YW-0038
|
0.38 | 0.67 | 300 | 1200 | 3 | 0.13 | 1 Fiber Braid |
|
1509YW-0050
|
0.50 | 0.77 | 300 | 1200 | 5 | 0.15 | 1 Fiber Braid |
|
1509YW-0063
|
0.63 | 0.93 | 300 | 1200 | 6 | 0.23 | 1 Fiber Braid |
|
1509YW-0075
|
0.75 | 1.04 | 300 | 1200 | 6 | 0.26 | 1 Fiber Braid |
