WH004
Product Specifications
- Winner Suction Hose
- Suitable for suction & transfer applications conveying oil, fuel, gasoline, and water based solutions
TUBE MATERIAL
NBR
COVER MATERIAL
Synthetic rubber
PRIMARY APPLICATION
Oil return lines, fuel oil, gasoline
APPROVALS
MSHA, USCG
TEMPERATURE MIN. (F)
-40
TEMPERATURE MAX. (F)
212
INDUSTRY STANDARDS
SAE 100R4
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) | HOSE O.D. (inches) | Working Pressure (PSI) | Burst Pressure (PSI) | Min. Bend Radius (Inches) | WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
WH004-12
|
0.75 | 1.18 | 305 | 1220 | 1.57 | 0.36 | Helical wire + anti-static wire |
|
WH004-16
|
1.00 | 1.43 | 245 | 980 | 1.77 | 0.46 | Helical wire + anti-static wire |
|
WH004-20
|
1.25 | 1.69 | 205 | 820 | 2.36 | 0.57 | Helical wire + anti-static wire |
|
WH004-24
|
1.50 | 1.98 | 150 | 600 | 2.56 | 0.81 | Helical wire + anti-static wire |
|
WH004-32
|
2.00 | 2.49 | 100 | 400 | 3.94 | 1.03 | Helical wire + anti-static wire |
|
WH004-40
|
2.50 | 3.02 | 60 | 240 | 5.51 | 1.38 | Helical wire + anti-static wire |
|
WH004-48
|
3.00 | 3.52 | 60 | 240 | 7.09 | 1.76 | Helical wire + anti-static wire |
