GH781
Product Specifications
- Aeroquip Core Premium Braided Hose
- Dura-Tuff™ cover provides 8x greater abrasion resistance than standard
- Transfer of medium to high pressure hydraulic & water based fluids
TUBE MATERIAL
Nitrile
COVER MATERIAL
Dura-Tuff™ Abrasion Res.
PRIMARY APPLICATION
Hydraulic / Fluid Power
APPROVALS
MSHA, ABS, DNV, USCG
TEMPERATURE MIN. (F)
-50
TEMPERATURE MAX. (F)
260
INDUSTRY STANDARDS
SAE 100R16
2ND STANDARD
EN 857 2SC
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) | HOSE O.D. (inches) | Working Pressure (PSI) | Burst Pressure (PSI) | Min. Bend Radius (Inches) | WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
GH781-4
|
0.25 | 0.55 | 6500 | 26000 | 1.96 | 0.22 | 2 Wire Braid |
|
GH781-6
|
0.38 | 0.69 | 5800 | 23200 | 2.55 | 0.29 | 2 Wire Braid |
|
GH781-8
|
0.50 | 0.82 | 5100 | 20400 | 3.54 | 0.39 | 2 Wire Braid |
|
GH781-10
|
0.63 | 0.94 | 4050 | 16200 | 3.94 | 0.44 | 2 Wire Braid |
|
GH781-12
|
0.75 | 1.10 | 3500 | 14000 | 4.72 | 0.53 | 2 Wire Braid |
|
GH781-16
|
1.00 | 1.40 | 3050 | 12200 | 5.90 | 0.72 | 2 Wire Braid |
|
GH781-20
|
1.25 | 1.71 | 2500 | 10000 | 8.26 | 1.09 | 2 Wire Braid |
|
GH781-24
|
1.50 | 2.03 | 2050 | 8200 | 9.84 | 1.40 | 2 Wire Braid |
|
GH781-32
|
2.00 | 2.52 | 1600 | 6400 | 12.40 | 1.90 | 2 Wire Braid |
