GH681
Product Specifications
- Aeroquip Core Premium Braided Hose
- Dura-Tuff™ cover provides 8x greater abrasion resistance than standard
- For medium pressure hydraulic & water based fluid applications where abrasion is of concern
TUBE MATERIAL
Nitrile
COVER MATERIAL
Dura-Tuff™ Abrasion Res.
PRIMARY APPLICATION
Hydraulic / Fluid Power
APPROVALS
MSHA, ABS, DNV, USCG
TEMPERATURE MIN. (F)
-50
TEMPERATURE MAX. (F)
260
INDUSTRY STANDARDS
SAE 100R17
2ND STANDARD
EN 857 1SC
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) | HOSE O.D. (inches) | Working Pressure (PSI) | Burst Pressure (PSI) | Min. Bend Radius (Inches) | WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
GH681-3
|
0.19 | 0.43 | 3650 | 14500 | 1.77 | 0.11 | 1 Wire Braid |
|
GH681-4
|
0.25 | 0.51 | 3700 | 14800 | 1.97 | 0.14 | 1 Wire Braid |
|
GH681-5
|
0.31 | 0.55 | 3250 | 13000 | 2.17 | 0.15 | 1 Wire Braid |
|
GH681-6
|
0.38 | 0.64 | 3400 | 13600 | 2.48 | 0.21 | 1 Wire Braid |
|
GH681-8
|
0.50 | 0.78 | 3200 | 12800 | 3.54 | 0.29 | 1 Wire Braid |
|
GH681-10
|
0.63 | 0.88 | 2025 | 8100 | 3.94 | 0.29 | 1 Wire Braid |
|
GH681-12
|
0.75 | 1.02 | 2000 | 8000 | 4.72 | 0.37 | 1 Wire Braid |
|
GH681-16
|
1.00 | 1.34 | 1500 | 6000 | 5.91 | 0.56 | 1 Wire Braid |
|
GH681-20
|
1.25 | 1.63 | 1000 | 4000 | 8.27 | 0.68 | 1 Wire Braid |
|
GH681-24
|
1.50 | 1.89 | 750 | 3000 | 9.84 | 0.83 | 1 Wire Braid |
|
GH681-32
|
2.00 | 2.52 | 600 | 2400 | 12.40 | 1.32 | 1 Wire Braid |
