GH194
Product Specifications
- Aeroquip Core Premium Braided Hose
- AQP® Patented elastomeric tube & cover for increased max temperature
- For hydraulic, crude, fuel & lubricating oils, water & phosphate ester based solutions
TUBE MATERIAL
AQP® (High-Temp)
COVER MATERIAL
AQP® (High-Temp)
PRIMARY APPLICATION
Hydraulic / Fluid Power
APPROVALS
MSHA, ABS, DNV
TEMPERATURE MIN. (F)
-40
TEMPERATURE MAX. (F)
302
INDUSTRY STANDARDS
SAE 100R1
2ND STANDARD
EN 853 1SN
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) | HOSE O.D. (inches) | Working Pressure (PSI) | Burst Pressure (PSI) | Min. Bend Radius (Inches) | WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
GH194-4
|
0.25 | 0.53 | 3250 | 13000 | 3.94 | 0.17 | 1 Wire Braid |
|
GH194-6
|
0.38 | 0.68 | 3125 | 12500 | 4.92 | 0.25 | 1 Wire Braid |
|
GH194-8
|
0.50 | 0.80 | 2550 | 10200 | 7.09 | 0.30 | 1 Wire Braid |
|
GH194-10
|
0.63 | 0.94 | 2050 | 8200 | 8.07 | 0.36 | 1 Wire Braid |
|
GH194-12
|
0.75 | 1.08 | 1800 | 7200 | 9.45 | 0.46 | 1 Wire Braid |
|
GH194-16
|
1.00 | 1.42 | 1300 | 5200 | 11.81 | 0.66 | 1 Wire Braid |
|
GH194-20
|
1.25 | 1.73 | 950 | 3800 | 16.54 | 0.85 | 1 Wire Braid |
|
GH194-24
|
1.50 | 1.99 | 725 | 2900 | 19.69 | 1.06 | 1 Wire Braid |
|
GH194-32
|
2.00 | 2.33 | 580 | 2320 | 24.80 | 1.37 | 1 Wire Braid |
