FC849
SAE 100R19Product Specifications
- Aeroquip Premium Braided Hose
- Dura-Tuff™ cover provides 8x greater abrasion resistance than standard
- For industrial & hydraulic systems with petroleum & water based fluids, construction & off-highway vehicles
TUBE MATERIAL
Nitrile
COVER MATERIAL
Dura-Tuff™ Abrasion Res.
PRIMARY APPLICATION
Hydraulic / Fluid Power
APPROVALS
MSHA , ABS, USCG
TEMPERATURE MIN. (F)
-40
TEMPERATURE MAX. (F)
212
INDUSTRY STANDARDS
SAE 100R19
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) |
HOSE O.D. (inches) |
Working Pressure (PSI) |
Burst Pressure (PSI) |
Min. Bend Radius (Inches) |
WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
FC849-04
|
0.25 | 0.59 | 4050 | 16200 | 1.97 | 0.24 | 2 Wire Braid |
|
FC849-06
|
0.38 | 0.75 | 4050 | 16200 | 2.5 | 0.36 | 2 Wire Braid |
|
FC849-08
|
0.5 | 0.87 | 4050 | 16200 | 3.5 | 0.43 | 2 Wire Braid |
|
FC849-10
|
0.63 | 1.01 | 4050 | 16200 | 3.94 | 0.6 | 2 Wire Braid |
|
FC849-12
|
0.75 | 1.17 | 4050 | 16200 | 4.72 | 0.72 | 2 Wire Braid |
