FC839B
Product Specifications
- Aeroquip Core Premium Braided Hose
- Bruiser® Ultra-abrasion resistant cover provides 700x greater abrasion resistance than standard
- For low to medium pressure hydraulic & water based fluid applications
TUBE MATERIAL
Nitrile
COVER MATERIAL
Bruiser® Ultra-Abrasion
PRIMARY APPLICATION
Hydraulic / Fluid Power
APPROVALS
MSHA
TEMPERATURE MIN. (F)
-40
TEMPERATURE MAX. (F)
212
INDUSTRY STANDARDS
SAE 100R17
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) | HOSE O.D. (inches) | Working Pressure (PSI) | Burst Pressure (PSI) | Min. Bend Radius (Inches) | WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
FC839B-04
|
0.25 | 0.50 | 3050 | 12200 | 1.97 | 0.15 | 1 Wire Braid |
|
FC839B-06
|
0.38 | 0.65 | 3050 | 12200 | 2.56 | 0.23 | 1 Wire Braid |
|
FC839B-08
|
0.50 | 0.82 | 3050 | 12200 | 3.54 | 0.32 | 1 Wire Braid |
|
FC839B-10
|
0.63 | 0.98 | 3050 | 12200 | 3.94 | 0.48 | 2 Wire Braid |
|
FC839B-12
|
0.75 | 1.12 | 3050 | 12200 | 4.72 | 0.60 | 2 Wire Braid |
|
FC839B-16
|
1.00 | 1.46 | 3050 | 12200 | 5.91 | 0.96 | 2 Wire Braid |
