FC735
SAE 100R16Product Specifications
- Aeroquip Core Premium Braided Hose
- Bruiser® Ultra-abrasion resistant cover provides 700x greater abrasion resistance than standard
- For higher pressure hydraulics subject to high surge peaks
TUBE MATERIAL
Nitrile
COVER MATERIAL
Bruiser® Ultra-Abrasion
PRIMARY APPLICATION
Hydraulic / Fluid Power
APPROVALS
MSHA, ABS, DNV
TEMPERATURE MIN. (F)
-40
TEMPERATURE MAX. (F)
260
INDUSTRY STANDARDS
SAE 100R16
2ND STANDARD
EN 857 2SC
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) |
HOSE O.D. (inches) |
Working Pressure (PSI) |
Burst Pressure (PSI) |
Min. Bend Radius (Inches) |
WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
FC735-04
|
0.25 | 0.55 | 6500 | 26025 | 1.97 | 0.21 | 2 Wire Braid |
|
FC735-06
|
0.38 | 0.69 | 5800 | 23200 | 2.56 | 0.28 | 2 Wire Braid |
|
FC735-08
|
0.5 | 0.82 | 5000 | 20000 | 3.54 | 0.33 | 2 Wire Braid |
|
FC735-10
|
0.63 | 0.98 | 4000 | 16060 | 3.94 | 0.48 | 2 Wire Braid |
|
FC735-12
|
0.75 | 1.12 | 3500 | 13960 | 4.72 | 0.56 | 2 Wire Braid |
|
FC735-16
|
1 | 1.41 | 3000 | 12000 | 5.91 | 0.8 | 2 Wire Braid |
|
FC735-20
|
1.25 | 1.7 | 2500 | 9965 | 8.27 | 1.02 | 2 Wire Braid |
