FC636
Product Specifications
- Aeroquip Premium Spiral Hose
- Ground Support Equipment (GSE), phosphate esterbased fluids, water/gylcol solutions
TUBE MATERIAL
EPDM
COVER MATERIAL
EPDM
PRIMARY APPLICATION
Phosphate ester solutions, glycol
TEMPERATURE MIN. (F)
-40
TEMPERATURE MAX. (F)
175
INDUSTRY STANDARDS
SAE 100R12
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) | HOSE O.D. (inches) | Working Pressure (PSI) | Burst Pressure (PSI) | Min. Bend Radius (Inches) | WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
FC636-12
|
0.75 | 1.21 | 4000 | 16000 | 9.50 | 0.88 | 4 Wire Spiral |
|
FC636-16
|
1.00 | 1.49 | 4000 | 16000 | 12.00 | 1.17 | 4 Wire Spiral |
|
FC636-20
|
1.25 | 1.83 | 3000 | 12000 | 16.50 | 1.55 | 4 Wire Spiral |
|
FC636-24
|
1.50 | 2.12 | 2500 | 10000 | 20.00 | 1.96 | 4 Wire Spiral |
