FC619
Product Specifications
- Aeroquip Premium Suction Hose
- AQP® Patented elastomeric cover for increased max temperature
- For suction and transfer of petroleum hydraulic fluids, fuels, lubrication oils & many industrial solutions
TUBE MATERIAL
AQP® (High-Temp)
COVER MATERIAL
Dura-Tuff™ Abrasion Res.
PRIMARY APPLICATION
Oil return lines, fuel oil, gasoline
APPROVALS
MSHA, ABS
TEMPERATURE MIN. (F)
-40
TEMPERATURE MAX. (F)
275
INDUSTRY STANDARDS
SAE 100R4
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) | HOSE O.D. (inches) | Working Pressure (PSI) | Burst Pressure (PSI) | Min. Bend Radius (Inches) | WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
FC619-12
|
0.75 | 1.18 | 305 | 1220 | 1.57 | 0.44 | Helical Wire |
|
FC619-16
|
1.00 | 1.46 | 245 | 980 | 1.77 | 0.52 | Helical Wire |
|
FC619-20
|
1.25 | 1.76 | 205 | 820 | 2.36 | 0.75 | Helical Wire |
|
FC619-24
|
1.50 | 2.01 | 150 | 600 | 2.56 | 0.85 | Helical Wire |
|
FC619-32
|
2.00 | 2.55 | 100 | 400 | 3.94 | 1.16 | Helical Wire |
|
FC619-40
|
2.50 | 3.06 | 60 | 240 | 5.51 | 1.58 | Helical Wire |
|
FC619-48
|
3.00 | 3.64 | 60 | 240 | 11.00 | 2.26 | Helical Wire |
