FC611
1-Wire EPDMProduct Specifications
- Aeroquip Premium Braided Hose
- Ground Support Equipment (GSE), phosphate esterbased fluids, water/gylcol solutions
TUBE MATERIAL
EPDM
COVER MATERIAL
EPDM
PRIMARY APPLICATION
Phosphate ester solutions, glycol
TEMPERATURE MIN. (F)
-40
TEMPERATURE MAX. (F)
175
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) |
HOSE O.D. (inches) |
Working Pressure (PSI) |
Burst Pressure (PSI) |
Min. Bend Radius (Inches) |
WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
FC611-12
|
0.75 | 1.09 | 1250 | 5000 | 9.5 | 0.42 | 1 Wire Braid |
|
FC611-16
|
1 | 1.4 | 1000 | 4000 | 12 | 0.6 | 1 Wire Braid |
|
FC611-20
|
1.25 | 1.73 | 625 | 2500 | 16.5 | 0.76 | 1 Wire Braid |
|
FC611-24
|
1.5 | 1.99 | 500 | 2000 | 20 | 1.02 | 1 Wire Braid |
|
FC611-32
|
2 | 2.51 | 375 | 1500 | 25 | 1.28 | 1 Wire Braid |
