EC525
Product Specifications
- Aeroquip Core Premium Spiral Hose
- AQP® Patented elastomeric tube & cover for increased max temperature
- For petroleum and fire-resistant fluids, fuels, lubricating oils, gasoline, and water-based solutions
TUBE MATERIAL
AQP® (High-Temp)
COVER MATERIAL
AQP® (High-Temp)
PRIMARY APPLICATION
Hydraulic / Fluid Power
APPROVALS
MSHA, DNV
TEMPERATURE MIN. (F)
-40
TEMPERATURE MAX. (F)
300
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) | HOSE O.D. (inches) | Working Pressure (PSI) | Burst Pressure (PSI) | Min. Bend Radius (Inches) | WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
EC525-12
|
0.75 | 1.21 | 5000 | 20000 | 9.50 | 0.86 | 4 Wire Spiral |
|
EC525-16
|
1.00 | 1.49 | 5000 | 20000 | 12.00 | 1.16 | 4 Wire Spiral |
|
EC525-20
|
1.25 | 1.83 | 3500 | 14000 | 16.50 | 1.55 | 4 Wire Spiral |
|
EC525-24
|
1.50 | 2.12 | 3500 | 14000 | 20.00 | 1.99 | 4 Wire Spiral |
|
EC525-32
|
2.00 | 2.65 | 3250 | 13000 | 25.00 | 2.97 | 6 Wire Spiral |
