EC420
Product Specifications
- Winner Spiral Hose
- For hydraulic systems with higher peak pressures and other strenuous applications
TUBE MATERIAL
Synthetic rubber
COVER MATERIAL
Synthetic rubber
PRIMARY APPLICATION
Hydraulic / Fluid Power
APPROVALS
MSHA, USCG
TEMPERATURE MIN. (F)
-40
TEMPERATURE MAX. (F)
250
INDUSTRY STANDARDS
SAE 100R13
2ND STANDARD
EN 856 R13
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) | HOSE O.D. (inches) | Working Pressure (PSI) | Burst Pressure (PSI) | Min. Bend Radius (Inches) | WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
EC420-12
|
0.75 | 1.27 | 5100 | 20400 | 4.72 | 1.03 | 4 Wire Spiral |
|
EC420-16
|
1.00 | 1.53 | 5100 | 20400 | 5.91 | 1.35 | 4 Wire Spiral |
|
EC420-20
|
1.25 | 1.96 | 5100 | 20400 | 8.27 | 2.54 | 6 Wire Spiral |
|
EC420-24
|
1.50 | 2.26 | 5100 | 20400 | 9.84 | 3.18 | 6 Wire Spiral |
|
EC420-32
|
2.00 | 2.82 | 5100 | 20400 | 12.60 | 4.21 | 6 Wire Spiral |
