EC415
Product Specifications
- Winner Spiral Hose
- For hydraulic system service with petroleum & water based fluids, general industrial service
TUBE MATERIAL
Synthetic rubber
COVER MATERIAL
Synthetic rubber
PRIMARY APPLICATION
Hydraulic / Fluid Power
APPROVALS
MSHA, USCG
TEMPERATURE MIN. (F)
-40
TEMPERATURE MAX. (F)
212
INDUSTRY STANDARDS
SAE 100R12
2ND STANDARD
EN 856 R12
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) | HOSE O.D. (inches) | Working Pressure (PSI) | Burst Pressure (PSI) | Min. Bend Radius (Inches) | WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
EC415-06
|
0.38 | 0.80 | 4050 | 16200 | 2.48 | 0.40 | 4 Wire Spiral |
|
EC415-08
|
0.50 | 0.94 | 4050 | 16200 | 3.54 | 0.50 | 4 Wire Spiral |
|
EC415-10
|
0.63 | 1.09 | 4050 | 16200 | 3.94 | 0.69 | 4 Wire Spiral |
|
EC415-12
|
0.75 | 1.21 | 4050 | 16200 | 4.72 | 0.78 | 4 Wire Spiral |
|
EC415-16
|
1.00 | 1.50 | 4050 | 16200 | 5.91 | 1.18 | 4 Wire Spiral |
|
EC415-20
|
1.25 | 1.85 | 3050 | 12200 | 8.27 | 1.65 | 4 Wire Spiral |
|
EC415-24
|
1.50 | 2.11 | 3000 | 12000 | 9.84 | 1.92 | 4 Wire Spiral |
|
EC415-32
|
2.00 | 2.63 | 3000 | 12000 | 12.60 | 2.70 | 4 Wire Spiral |
