2661
Product Specifications
- Aeroquip Premium Suction Hose
- AQP® Patented elastomeric tube & cover for increased max temperature
- For suction and transfer applications with fire-resistant hydraulic fluids & other eleveated temperature fluid applications
TUBE MATERIAL
AQP® (High-Temp)
COVER MATERIAL
AQP® (High-Temp)
PRIMARY APPLICATION
Oil return lines, fuel oil, gasoline
APPROVALS
MSHA, ABS, USCG
TEMPERATURE MIN. (F)
-40
TEMPERATURE MAX. (F)
300
INDUSTRY STANDARDS
SAE 100R4
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) | HOSE O.D. (inches) | Working Pressure (PSI) | Burst Pressure (PSI) | Min. Bend Radius (Inches) | WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
2661-12
|
0.75 | 1.25 | 305 | 1220 | 4.92 | 0.42 | Helical Wire |
|
2661-16
|
1.00 | 1.50 | 255 | 1020 | 5.91 | 0.50 | Helical Wire |
|
2661-20
|
1.25 | 1.80 | 205 | 820 | 7.87 | 0.90 | Helical Wire |
|
2661-24
|
1.50 | 2.09 | 160 | 640 | 10.04 | 1.13 | Helical Wire |
|
2661-32
|
2.00 | 2.55 | 100 | 400 | 11.81 | 1.30 | Helical Wire |
|
2661-40
|
2.50 | 3.07 | 65 | 260 | 13.98 | 1.72 | Helical Wire |
|
2661-48
|
3.00 | 3.64 | 60 | 240 | 17.99 | 1.96 | Helical Wire |
|
2661-64
|
4.00 | 4.69 | 50 | 200 | 24.02 | 3.08 | Helical Wire |
