EHW194
Product Specifications
- Blue (Layline Only)
- 100% Sulfur free construction
TUBE MATERIAL
EPDM-Peroxide Cured
COVER MATERIAL
EPDM
PRIMARY APPLICATION
Data Center Liquid Cooling
APPROVALS
UL 94 V-0
TEMPERATURE MIN. (F)
-40
TEMPERATURE MAX. (F)
284
Our Range of Products
Export Specifications
| PART # | HOSE I.D. (inches) | HOSE O.D. (inches) | Working Pressure (PSI) | Burst Pressure (PSI) | Min. Bend Radius (Inches) | WEIGHT: LBS / FT | REINFORCEMENT |
|---|---|---|---|---|---|---|---|
|
EHW194-08BK
|
0.50 | 0.87 | 232 | 696 | 3.00 | 0.24 | 2-Ply Textile |
|
EHW194-08RD
|
0.50 | 0.87 | 232 | 696 | 3.00 | 0.24 | 2-Ply Textile |
|
EHW194-08BU
|
0.50 | 0.87 | 232 | 696 | 3.00 | 0.24 | 2-Ply Textile |
|
EHW194-10BK
|
0.63 | 0.99 | 232 | 696 | 4.00 | 0.29 | 2-Ply Textile |
|
EHW194-10RD
|
0.63 | 0.99 | 232 | 696 | 4.00 | 0.29 | 2-Ply Textile |
|
EHW194-10BU
|
0.63 | 0.99 | 232 | 696 | 4.00 | 0.29 | 2-Ply Textile |
|
EHW194-12BK
|
0.75 | 1.17 | 232 | 696 | 5.00 | 0.38 | 2-Ply Textile |
|
EHW194-12RD
|
0.75 | 1.17 | 232 | 696 | 5.00 | 0.38 | 2-Ply Textile |
|
EHW194-12BU
|
0.75 | 1.17 | 232 | 696 | 5.00 | 0.38 | 2-Ply Textile |
|
EHW194-16BK
|
1.00 | 1.44 | 232 | 696 | 6.00 | 0.50 | 2-Ply Textile |
|
EHW194-16RD
|
1.00 | 1.44 | 232 | 696 | 6.00 | 0.50 | 2-Ply Textile |
|
EHW194-16BU
|
1.00 | 1.44 | 232 | 696 | 6.00 | 0.50 | 2-Ply Textile |
|
EHW194TW-04BK
|
0.25 | 0.51 | 218 | 696 | 1.00 | 0.14 | 2-Ply Textile |
|
EHW194TW-04RD
|
0.25 | 0.51 | 218 | 696 | 1.00 | 0.14 | 2-Ply Textile |
|
EHW194TW-04BU
|
0.25 | 0.51 | 218 | 696 | 1.00 | 0.14 | 2-Ply Textile |
|
EHW194TW-06BK
|
0.38 | 0.63 | 218 | 696 | 1.40 | 0.19 | 2-Ply Textile |
|
EHW194TW-06RD
|
0.38 | 0.63 | 218 | 696 | 1.40 | 0.19 | 2-Ply Textile |
|
EHW194TW-06BU
|
0.38 | 0.63 | 218 | 696 | 1.40 | 0.19 | 2-Ply Textile |
|
EHW194-20RD
|
1.25 | 1.73 | 150 | 600 | 3.20 | 0.71 | Helical Wire & Textile Plies |
|
EHW194-20BU
|
1.25 | 1.73 | 150 | 600 | 3.20 | 0.71 | Helical Wire & Textile Plies |
|
EHW194-24RD
|
1.50 | 1.97 | 150 | 600 | 3.50 | 0.81 | Helical Wire & Textile Plies |
|
EHW194-24BU
|
1.50 | 1.97 | 150 | 600 | 3.50 | 0.81 | Helical Wire & Textile Plies |
|
EHW194-32RD
|
2.00 | 2.52 | 150 | 600 | 4.70 | 1.18 | Helical Wire & Textile Plies |
|
EHW194-32BU
|
2.00 | 2.52 | 150 | 600 | 4.70 | 1.18 | Helical Wire & Textile Plies |
